The Ultra-Thin Horizontal Concealed Fan Coil Unit is an upgraded version of the standard horizontal concealed model, with body thickness compressed to just 205mm and depth to 440mm — only 60% the volume of conventional units. Indoor clear height increases by 100-150mm, eliminating the oppressive feeling of low ceilings.
Modern residential market including furnished apartments and villas; hotel guestrooms, offices, hospital wards, and high-end commercial spaces; retrofit projects with limited ceiling clearance.
Identical to the standard horizontal concealed fan coil unit. The fan forces indoor air through the internal heat exchanger coil containing chilled or hot water for heat exchange. Cooled or heated air is returned to the room, continuously circulating to regulate temperature.
