The 8-Way Cassette Fan Coil Unit adds an additional air outlet group on each side of the conventional 4-way design, totaling 8 discharge positions for higher air delivery density and wider coverage. The center-return, 8-directional surround-discharge airflow pattern delivers softer, more uniform air distribution without localized hot or cold spots — ideal for large square retail spaces, exhibition halls, conference rooms, and hotel lobbies.
Industrial and civil building air conditioning for textile/garment, machinery manufacturing, metallurgy/chemical, electronics/power, and medical/pharmaceutical applications; large-area venues including broadcast halls, shopping malls, entertainment centers, theaters, and stadiums.
The central AC chiller delivers chilled/hot water through supply piping and motorized valve into the 8-way cassette heat exchanger, with return water flowing back to the chiller. Indoor air enters through the central return grille, passes through the cooling/heating coil for heat exchange, and is discharged from 8 outlets at multiple angles. Condensate is automatically pumped out, achieving uniform cooling and heating across large spaces.
