The Horizontal Exposed Fan Coil Unit is suspended directly from the ceiling without requiring a suspended ceiling structure, making it ideal for spaces with limited height or finished renovations. The unit features a powder-coated or baked-enamel finish for an attractive appearance, with easy installation and maintenance access.
The fan draws room air through the return grille into the unit, passes it through an air filter to remove dust, then forces it across the internal coil. During cooling, chilled water circulates through the coil, absorbing heat from the air while condensate drains via the drain pan; during heating, hot water warms the air. The conditioned air is returned to the room through the supply outlet, continuously regulating room temperature.
