The 2-Way Cassette Fan Coil Unit features adjustable guide louvers on both left and right sides for bidirectional discharge, with a unified bottom-center return grille creating a "center-return, dual-side discharge" airflow pattern. Compared to 1-way models, it achieves longer throw distance, wider coverage, and more uniform room temperature.
Industrial and civil buildings including textile/garment, machinery, metallurgy/chemical, electronics/power, and medical/pharmaceutical applications; particularly suited for rectangular offices, shops, corridors, standard hotel rooms, and narrow ceiling areas.
The chiller delivers chilled/hot water through supply piping and motorized valve to the 2-way cassette heat exchanger, with return water completing the water circuit. Indoor air enters through the center return grille, passes through the cooling/heating coil, and is discharged bidirectionally from left and right outlets. Condensate is automatically pumped out for continuous temperature control.
