The 4-Way Cassette Fan Coil Unit features four air outlets arranged in a cross pattern for 360° omni-directional airflow with maximum coverage. The center-return, four-side discharge airflow pattern achieves far superior temperature uniformity compared to 1-way and 2-way models, with no noticeable hot or cold dead zones. Each louver is independently adjustable to prevent direct airflow on occupants.
Industrial and civil buildings including textile/garment, machinery, metallurgy/chemical, electronics/power, and medical/pharmaceutical applications; venues such as broadcast halls, conference rooms, hotels, shopping malls, entertainment centers, theaters, and stadiums.
The chiller delivers chilled/hot water through supply piping and motorized valve to the 4-way cassette heat exchanger, with return water completing the circuit. Indoor air enters through the center return grille, passes through the cooling/heating coil, and is discharged uniformly from four outlets in a 360° pattern. Condensate is automatically pumped out for whole-room cooling and heating.
